WHO WE ARE
We are a Russian team of professionals who have been developing and producing polymer membranes for over 30 years.
We built the first production plant in Russia which producing ultrafiltration modules. We make hollow fiber ultrafiltration membranes from PES and PVDF polymers using proven, perfected technology that provides characteristics that surpass competitors, and, therefore, allows our customers to receive modules with the highest quality.
We built the first production plant in Russia which producing ultrafiltration modules. We make hollow fiber ultrafiltration membranes from PES and PVDF polymers using proven, perfected technology that provides characteristics that surpass competitors, and, therefore, allows our customers to receive modules with the highest quality.
MODERN ULTRAFILTRATION MODULES PRODUCTION
We have our own technologies for the production of hollow fiber ultrafiltration membranes from polyethersulfone (PES) polymer and polyvinylidene fluoride (PVDF) polymer
PES HOLLOW FIBER ULTRAFILTRATION MEMBRANE
The membrane's selective layer is located on the inner surface, thus implementing the "inside-out" operating mode. The fiber has a sponge like structure (without macrovoids) with an average selective pore of 20 nm and a outer surface with high porosity.
MEMBRANE CROSS SECTION
MEMBRANE WALL
INNER SURFACE
OUTER SURFACE
PVDF HOLLOW FIBER ULTRAFILTRATION MEMBRANE
The membrane's selective layer is located on the outer surface, thus implementing the "outside-in" operating mode. The fiber has a sponge like structure (without macrovoids) with an average selective pore of 25 nm.
MEMBRANE CROSS SECTION
MEMBRANE WALL
INNER SURFACE
OUTER SURFACE
WHAT WE PRODUCE
Ultrafiltration modules with «inside-out» operation mode
Our own housing:
Analog companies housing:
Pentair Aquaflex 55 (shell supplied with fibres)
Pentair Aquaflex 55 (shell supplied with fibres)
Our company has successfully replaced 1,680 units of Pentair Aquaflex 55 modules to TMT-UFPES-A at the Western Water Treatment Plant of Mosvodokanal JSC. This project required the transition of production to continuous operation and maintaining this pace for six months.
INGE Dizzer 5000 / SUEZ ZeeWeed IMT - 10060 UF/M
Our company has mastered the production of ultrafiltration modules in the NGE / SUEZ housing. A distinctive feature of this housing is the absence of a central perforated filtrate outlet pipe. The filtrate is discharged through a side pipe in the housing itself. Now we can change the NGE / SUEZ ultrafiltration modules without additional strapping one to one.
INGE Dizzer 5000 / SUEZ ZeeWeed IMT - 10060 UF/M
(modules without covers only the housing part with fiber)
(modules without covers only the housing part with fiber)
We also sell modules without covers only the housing part with fiber.
The connection is made to the original INGE covers or to the INGE T RACK.
The connection is made to the original INGE covers or to the INGE T RACK.
Ultrafiltration modules with «outside-in» operation mode
Our own housing:
Our own housing:
Analog companies housing:
DuPont SF – 2880 (delivery without caps is allowed)
DuPont SF – 2880 (delivery without caps is allowed)
UF 6060
Hydronautics MAX 80, MAX 60
EQUIPMENT FOR INDUSTRIAL MEMBRANE WATER TREATMENT SYSTEMS
In addition to ultrafiltration modules we producing ready-made installations for the construction of industrial membrane water treatment systems, including LSAU, for engineering companies:
- ultrafiltration SKID (90m3/h)
- 1-stage reverse osmosis system (72 m3/h)
- 2-stage system (32 m3/h)
- CIP cleaning SKID unit
- reagent dosing SKID unit (acid, alkali, GHNA, coagulant, etc.)
- pumping stations
- COMPLETE INDUSTRIAL ULTRAFILTRATION SKIDSKID composition:Request
Technological unit of input of ultrafiltration SKID:- Steel frame
- Set of process pipelines
- Set of shut-off and control valves
- Set of control and measuring instruments
- Automatic control cabinet
- Circulation pump
- Process air compressor
- INDUSTRIAL REVERSE OSMOSIS SKIDSKID composition:Request
- Steel frame
- Membrane housings
- Membrane elements
- Set of process pipelines
- Cartridge and multi-cartridge filter (5 microns)
- High pressure pumps
- Control and power supply cabinets
- Inhibitor dosing unit
- Set of shut-off and control valves
- Set of control and measuring instruments
WHY WE ARE BETTER
Compared to Chinese manufacturers the products of the TECON MEMBRANE TECHNOLOGIES company, at the same price level, significantly win in terms of quality:
- the actual pore size of 20 nm on the surface of the selective layer, as well as the absence of defects and macrovoids (large pores), ensures the highest quality of water cleaning;
- the increased permeability of the hollow fiber membrane reduces the operating costs of the water treatment plant: chemical cleanings are carried out less frequently, and less numbers of the modules are required to achieve the specified flow;
- quality control at every stage of fiber and module production. 100% of products undergo factory testing before shipment to the customer.
Compared to European manufacturers, the products of the TECON MEMBRANE TECHNOLOGIES company are significantly cheaper with the same quality of products.
WHERE IS IT ALREADY WORKING?
